MSI FZE offers a range of auxiliary equipment and certified support packages to complement stimulation and cementing operations. All units can be supplied as standalone packages or integrated with MSI equipment.

Dimensions: 6058 mm (L) × 2438 mm (W) × 2592 mm (H)

    • Electrical Input: 380–690V, 3 Phase, 50/60 Hz
    • Output Voltage: 380V / 3P / 50/60 Hz
    • Transformer: 23 KVA, 6-tap (1 unit)
    • Power Outlets: 220V and 110V
    • Operational Temperature: –20°C to +55°C

Packaged AC: 2 Ton duty + 2 Ton standby

    • Cooling Capacity: 24,000 BTU/h
    • Heating Capacity: 6 kW
    • Pressurization fan with pressure switch

Fully automatic fire & gas detection and shutdown

    • ATEX Exd IIB CPFG wall-mounted panel
    • H S detector (1) and HC detectors (2)
    • Optical smoke and heat detectors
    • Automatic fire dampers (fail-safe)
    • IS sounder and manual call point
    • Fire break glass
    • Fire extinguishers and first aid kit

A60 fire-rated insulation (walls, roof, floor)

    • Floating marine floor with vinyl finish
    • A60 windows (2 units)
    • A60 weather-tight external doors (3 units)
    • B15 internal airlock door with A60 sight glass
    • A60 emergency escape hatch
    • Marine-grade 240 DFT three-coat paint system
    • DNV-certified lifting slings and shackles

Electrical cabling per DNV 2.7-2

    • CAT 6 data and telephone points
    • Certified PA speaker
    • Robust custom work desk, overhead cabinets, and chairs
  • DNV Approved
    • ATEX Compliant
    • SOLAS Compliant
    • Structural: DNV 2.7-1
    • Electrical: DNV 2.7-2
    • Area Classification: Zone 1 / Zone 2
    • Test cabin
    • Data room
    • Zone 1 / Zone 2 workshop
    • Mud logging cabin
    • Well-site cabin
    • Wireline support cabin
    • Hazardous material storage
    • Ex-rated telephones
    • Flat-screen monitors
    • UPS systems
    • Custom cabinets and furniture

Heavy-duty stackable anchor blocks available in:

    • 10 TONNES
    • 20 TONNES

Designed for secure equipment anchoring and field deployment.

    • Available Capacities: 500 and 2,500 gallons

Double-wall fuel tanks are engineered to provide safe, vented storage for diesel fuel and similar products requiring secondary containment.

Units feature a primary storage tank enclosed within an outer containment wall for enhanced environmental protection and spill prevention.
